uk.ac.ed.epcc.webapp.model.data

Class Repository

java.lang.Object

uk.ac.ed.epcc.webapp.model.data.Repository

All Implemented Interfaces:

AppContextCleanup

public final class Repository
extends java.lang.Object
implements AppContextCleanup

Repository encapsulates a Database table. This class is used to hold the Connection (via the AppContext) and to cache information about the table including the name and meta-data. Actual rows are stored in Record objects which are inner classes of Repository to allow them to access the cached information.

Each record is assumed to have a unique integer identifier that can be used to reference the appropriate table record. The Repository.FieldInfo class records information about each field in the table. This class attempts to capture where a field is used to reference the integer identifier of a different table. This can be determined automatically where there is a foreign key constraint or can be specified using properties. A property reference.repository-tag.DBfield defines the name of the table the field references. If a handler class is registered for the remote table this is used to create a TypeProducer for the field. Alternatively a reference can be registered explicitly with the Repository by registering a TypeProducer for the field. This will reduce overhead where an instance of the remote handler class is already available.

A boolean property of the form truncate.repository-tag.DBfield can be used to request that field values be truncated to the database field length when being stored.

At the moment the integer identifier is implemented by requiring each tables to have a primary key consisting of a mysql auto_increment field if the is more than one auto_increment field the first is taken. This dependency on mysql specific features is encapsulated within the MysqlRepository class and could be replaced by a different class. Alternative DB back-ends can be less flexible than mysql when it comes to table and field names so SQL statements should be constructed using the addUniqueName addTable and FieldInfo.addName method calls as this allows the Repository class to perform name mangling via the following properties:

• table.tag defines the table name corresponding to tag. Defaults to tag
• rename.table-name.field-name defines the name the java code uses to refer to a database field. Defaults to field-name

The getParamTag() method returns a String to be used in looking up configuration parameters for the enclosing object. This defaults to tag but can be overridden by setting the config.tag property.

If the table_alias.tag<\b> property is set this is used as an alias string when constructing SQL statements. This is needed because the join filter classes assume a single reference between tables. If you have multiple fields that reference the same table you can register the same table under different tags with different aliases allowing multiple joins to the same table.

New Repository objects are obtained using a static method.

 AppContext c;
 Repository rep = Repository.getInstance(c,tag_name);


Repositories created in this way are cached in the AppContext so only a single Repository for each tag is ever created per AppContext. The tag is normally the same as the database table and should match the tag used to create the corresponding DataObjectFactory from the AppContext. However the tag should not be used as a table name in SQL as it is possible for table renaming and name-mangling to occur.

Repository can implement a cache of Record data based on id. This is enabled on a table by table basis via the cache.tag-name property. This is only intended to cache values within the lifetime of an AppContext (ie during a single request). The cache is populated whenever SetContents is called with the record ejected whenever put is called. This is to ensure the cache never contains a dirty record. The cache should also be flushed if the table is modified directly via an SQL update, though this is only an issue if a single request re-fetches records after a SQL update. The setID checks for cached data and populates itself by copying the cached record instead of fetching a database record. The cache only holds non-dirty data so could hold normal Map objects rather than actual Records. Currently this is left as a future optimisation.

Note that lookups via a TypeProducer may also utilise this caching mechanism.

Repositories are intended to be local to a parent AppContext which should represent a single thread of execution. However synchronisation is implemented within the code. The cost of this should be quite low and it also seems to prevent optimisation bugs in some JVMs

The Repository class implements some additional automatic type conversions beyond those implemented in JDBC.

• Boolean values can be stored as Strings taking the (T/F or True/False).
• Date time values can be stored as integers. These are always relative to the Unix epoch and default to being seconds. A different time unit can be selected by setting repository.resolution.table-name to be the number of milliseconds in the desired unit.
• StreamData values are always added as binary streams so they can be stored in blob types.

If a string attribute BACKUP_SUFFIX_ATTR is stored in the AppContext then this name will be used as a table name suffix to create backup tables where deleted records will be copied before being deleted in the main table. This is intended to allow old data to be backed up as part of a purge of data from a live table.

Nested Class Summary

Nested Classes

Modifier and Type	Class and Description
class	Repository.FieldInfo Information about fields
static class	Repository.IdMode modes supported by Repository.Record.setID(int)
class	Repository.IndexInfo information about indexes
class	Repository.Order Class representing an Order clause
class	Repository.Record Record encapsulates a Database record.

Field Summary

Fields

Modifier and Type	Field and Description
static java.lang.String	BACKUP_SUFFIX_ATTR
static Feature	BACKUP_WITH_SELECT
static java.lang.String	CACHE_FEATURE_PREFIX
static Feature	CHECK_INDEX
protected static java.lang.String	CONFIG_TAG_PREFIX
static Feature	READ_ONLY_FEATURE
static java.lang.String	REFERENCE_PREFIX
static Feature	REQUIRE_ID_KEY
protected boolean	use_id can we use the unique id code for this table

Constructor Summary

Constructors

Modifier	Constructor and Description
protected	Repository(AppContext c, java.lang.String tag) Create a Repository object private to force the use of the Factory method.

Method Summary

Modifier and Type	Method and Description
java.lang.StringBuilder	addAlias(java.lang.StringBuilder sb, boolean quote) Add the table alias
java.lang.StringBuilder	addSource(java.lang.StringBuilder sb, boolean quote) Add the table as a query source.
java.lang.StringBuilder	addTable(java.lang.StringBuilder sb, boolean quote) Add the table name to a query.
void	addTypeProducer(TypeProducer producer) Cache a TypeProducer in the repository.
java.lang.StringBuilder	addUniqueName(java.lang.StringBuilder sb, boolean qualify, boolean quote) Add the primary key name of this table to a query
void	cleanup() AppContext is being closed.
protected void	clearCache() clear the Record cache.
protected void	clearFields()
<T> T	convert(java.lang.Class<? extends T> target, java.lang.Object value)
java.lang.Object	convert(java.lang.String key, java.lang.Object value) Performs automatic type conversions to the canonical type as specified by the database table.
java.lang.Boolean	convertBoolean(java.lang.Object o, java.lang.Boolean def)
java.util.Date	convertDate(java.lang.Object o) perform any conversions to Date supported by this Repository.
java.lang.Number	convertNumber(java.lang.Object o) Perform any object conversions to Number appropriate to thisRepository.
void	createBackupTable(java.lang.String name)
java.lang.String	dbFieldtoTag(java.lang.String name) Map the actual name of the DB field to the tag used in the code.
boolean	equals(java.lang.Object obj)
void	flushCache()
static void	flushCaches(AppContext c)
Repository	getBackup() create a backup table structured like this one if backups are enabled.
<X extends DataObject> BooleanFieldExpression<X>	getBooleanExpression(java.lang.Class<X> filter_type, java.lang.String key) get a BooleanFieldExpression for a field
AppContext	getContext() get the AppContext associated with this Repository.
<X extends DataObject> FieldValue<java.util.Date,X>	getDateExpression(java.lang.Class<X> target, java.lang.String key) get a Date valued FieldValue for a field.
java.lang.String	getDBTag() Get the tag used to retrieve the correct database connection for this table from a DatabaseService
java.util.Set<java.lang.String>	getFields() get the list of Record fields for this table in canonical order.
static java.lang.String	getForeignKeyDescriptor(AppContext c, java.lang.String tag, boolean quote) Get a foreign key descriptor by tag.
Repository.IndexInfo	getIndexInfo(java.lang.String name)
java.util.Set<java.lang.String>	getIndexNames()
java.util.Collection<Repository.FieldInfo>	getInfo() Get all the FieldInfo objects for this Repository
Repository.FieldInfo	getInfo(java.lang.String key) get the FieldInfo object for a field null key always returns a null result
<T extends java.lang.Number,X extends DataObject> NumberFieldExpression<T,X>	getNumberExpression(java.lang.Class<X> filter_type, java.lang.Class<T> target, java.lang.String key) get a NumberFieldExpression for a field.
Repository.Order	getOrder(java.lang.String key, boolean desc) get a Repository.Order element corresponding to a key.
java.lang.String	getParamTag() get the tag used to qualify configuration parameters.
<T extends DataObject> IndexedFieldValue	getReferenceExpression(java.lang.Class<T> self, java.lang.String key) Get a IndexedFieldValue for a reference field
<T extends DataObject,I extends DataObject> IndexedFieldValue<T,I>	getReferenceExpression(java.lang.Class<T> self, java.lang.String key, IndexedProducer<I> prod) Get a IndexedFieldValue for a field The field does not have to be tagged as a reference field
long	getResolution() Return the number of milliseconds per tick to use when using an integer type to specify a date or vice versa.
IndexedTypeProducer	getSelfProducer()
SQLContext	getSQLContext()
<X extends DataObject> StringFieldExpression<X>	getStringExpression(java.lang.Class<X> filter_type, java.lang.String key) get a StringFieldExpression for a field
java.lang.String	getTable()
java.lang.String	getTag() Get the Tag string used to reference this Repository
<T extends DataObject,O,D> TypeProducerFieldValue<T,O,D>	getTypeProducerExpression(TypeProducer<O,D> prod)
protected java.lang.String	getUniqueIdName() get the field name of the primary key
protected java.lang.String	getUniqueIdName(boolean qualify)
boolean	hasField(Repository.FieldInfo info)
boolean	hasField(java.lang.String key) Is the specified object a valid Field key for this table.
int	hashCode()
boolean	hasIndex(java.lang.String index) Is there a named index of the specified name for this table.
boolean	hasTypeProducer(java.lang.String field)
protected int	insert(Repository.Record r) Default insert operation that uses Generated Keys to obtain the unique id.
boolean	isUniqueIdName(java.lang.String name) Is this the primary key field.
static <T> T	makeTargetObject(java.lang.Class<T> target, java.sql.ResultSet rs, int pos) Static method to result a field from a result set with a specified target class
static void	reset(AppContext c, java.lang.String tag) Clear the cached repository
boolean	setAllowBogusPut(boolean f) control if it is an error to set a property with no corresponding database field.
boolean	setAllowNull(boolean f) control if it is an error to set a property with a null value
void	setFromResultSet(Repository.Record r, java.sql.ResultSet rs, boolean qualify) populate an object from a ResultSet It seems to work if we always qualify the field names but its slower
void	setResolution(long resolution)
static java.lang.String	TableToTag(AppContext c, java.lang.String tag)
static java.lang.String	tagToTable(AppContext ctx, java.lang.String tag) Map a tag name to the actual database table.
java.lang.String	toString()
static java.lang.String	typeName(int type)
boolean	useID() Does this repository support id fields.
boolean	usesAlias()
boolean	usesCache()

Methods inherited from class java.lang.Object

clone, finalize, getClass, notify, notifyAll, wait, wait, wait

Field Detail

CONFIG_TAG_PREFIX

protected static final java.lang.String CONFIG_TAG_PREFIX

See Also:

Constant Field Values

BACKUP_SUFFIX_ATTR

public static final java.lang.String BACKUP_SUFFIX_ATTR

See Also:

Constant Field Values

REFERENCE_PREFIX

public static final java.lang.String REFERENCE_PREFIX

See Also:

Constant Field Values

CACHE_FEATURE_PREFIX

public static final java.lang.String CACHE_FEATURE_PREFIX

See Also:

Constant Field Values

REQUIRE_ID_KEY

public static final Feature REQUIRE_ID_KEY

CHECK_INDEX

public static final Feature CHECK_INDEX

READ_ONLY_FEATURE

public static final Feature READ_ONLY_FEATURE

BACKUP_WITH_SELECT

public static final Feature BACKUP_WITH_SELECT

use_id

protected final boolean use_id

can we use the unique id code for this table

Constructor Detail

Repository

protected Repository(AppContext c,
                     java.lang.String tag)
              throws java.sql.SQLException

Create a Repository object private to force the use of the Factory method.

Parameters:

c - AppContext

tag - String tag used to find repository.

Throws:

java.sql.SQLException

Method Detail

createBackupTable

public void createBackupTable(java.lang.String name)
                       throws java.sql.SQLException

Throws:

java.sql.SQLException

getBackup

public Repository getBackup()
                     throws DataFault

create a backup table structured like this one if backups are enabled.

Returns:

Repository or null

Throws:

DataFault

TableToTag

public static java.lang.String TableToTag(AppContext c,
                                          java.lang.String tag)

addUniqueName

public java.lang.StringBuilder addUniqueName(java.lang.StringBuilder sb,
                                             boolean qualify,
                                             boolean quote)

Add the primary key name of this table to a query

Parameters:

sb - StringBuilder

qualify - boolean should we qualify with table name

quote - boolean request quoting if supported

Returns:

modified StringBuilder

addTable

public java.lang.StringBuilder addTable(java.lang.StringBuilder sb,
                                        boolean quote)

Add the table name to a query. If this method is used to construct SQL statements then Repository sub-classes can implement table name mangling if required. Use this for schema updates but useaddSource(StringBuilder, boolean) in preference for select/update statements as qualified field names will use the alias

Parameters:

sb - StringBuilder

quote - request quoting if supported

Returns:

modified StringBuilder

See Also:

addSource(StringBuilder, boolean)

addAlias

public java.lang.StringBuilder addAlias(java.lang.StringBuilder sb,
                                        boolean quote)

Add the table alias

Parameters:

sb -

quote -

Returns:

modified StringBuilder

addSource

public java.lang.StringBuilder addSource(java.lang.StringBuilder sb,
                                         boolean quote)

Add the table as a query source. Normally the same as addTable(StringBuilder, boolean) but is allowed to add an "AS alias" clause as well

Parameters:

sb -

quote -

Returns:

modified StringBuilder

getTable

public java.lang.String getTable()

getSelfProducer

public IndexedTypeProducer getSelfProducer()

convert

public java.lang.Object convert(java.lang.String key,
                                java.lang.Object value)

Performs automatic type conversions to the canonical type as specified by the database table. This is to provide automatic casting based on the DB field type beyond that supported intrinsically in JDBC e.g. between Date and integer time fields. Note that Filters that generate their own SQL fragments will need to call this explicitly

Parameters:

key - Database field to base conversion on

value - input object

Returns:

converted object

convert

public <T> T convert(java.lang.Class<? extends T> target,
                     java.lang.Object value)

clearCache

protected void clearCache()

clear the Record cache.

clearFields

protected void clearFields()

convertDate

public final java.util.Date convertDate(java.lang.Object o)

perform any conversions to Date supported by this Repository. This is public so external code that queries directly can use them.

Parameters:

o - Input Object

Returns:

Number

convertNumber

public final java.lang.Number convertNumber(java.lang.Object o)

Perform any object conversions to Number appropriate to thisRepository. This is public so external code that queries directly can also use them

Parameters:

o - input Object

Returns:

Number

convertBoolean

public final java.lang.Boolean convertBoolean(java.lang.Object o,
                                              java.lang.Boolean def)

addTypeProducer

public void addTypeProducer(TypeProducer producer)

Cache a TypeProducer in the repository. This allows the basic database meta-data to be augmented by run-time information.

Parameters:

producer -

hasTypeProducer

public boolean hasTypeProducer(java.lang.String field)

getContext

public AppContext getContext()

get the AppContext associated with this Repository.

Returns:

the AppContext

flushCache

public final void flushCache()

getFields

public java.util.Set<java.lang.String> getFields()

get the list of Record fields for this table in canonical order.

Returns:

Set of field names or null if Repository invalid

hasField

public boolean hasField(Repository.FieldInfo info)

getIndexNames

public java.util.Set<java.lang.String> getIndexNames()

getIndexInfo

public Repository.IndexInfo getIndexInfo(java.lang.String name)

getInfo

public java.util.Collection<Repository.FieldInfo> getInfo()

Get all the FieldInfo objects for this Repository

Returns:

Collection

getInfo

public Repository.FieldInfo getInfo(java.lang.String key)

get the FieldInfo object for a field null key always returns a null result

Parameters:

key -

Returns:

FieldInfo

getOrder

public Repository.Order getOrder(java.lang.String key,
                                 boolean desc)

get a Repository.Order element corresponding to a key.

Parameters:

key - field to order by (null for primary key).

desc -

Returns:

Repository.Order

getSQLContext

public final SQLContext getSQLContext()

getResolution

public long getResolution()

Return the number of milliseconds per tick to use when using an integer type to specify a date or vice versa.

Returns:

the resolution

getTag

public java.lang.String getTag()

Get the Tag string used to reference this Repository

Returns:

String

getParamTag

public java.lang.String getParamTag()

get the tag used to qualify configuration parameters. This is normally the same as the reference tag but can be overridden to make it easy to support rolled-tables.

Returns:

String tag

getDBTag

public final java.lang.String getDBTag()

Get the tag used to retrieve the correct database connection for this table from a DatabaseService

Returns:

tag

getUniqueIdName

protected java.lang.String getUniqueIdName()

get the field name of the primary key

Returns:

String

isUniqueIdName

public boolean isUniqueIdName(java.lang.String name)

Is this the primary key field. Safer to provide a test than a query method as it can't be used to write a ad-hoc sql query.

Parameters:

name -

Returns:

boolean

getUniqueIdName

protected java.lang.String getUniqueIdName(boolean qualify)

hasField

public boolean hasField(java.lang.String key)

Is the specified object a valid Field key for this table.

Parameters:

key -

Returns:

boolean true if key is valid

hasIndex

public boolean hasIndex(java.lang.String index)

Is there a named index of the specified name for this table.

Parameters:

index -

Returns:

boolean

getNumberExpression

public <T extends java.lang.Number,X extends DataObject> NumberFieldExpression<T,X> getNumberExpression(java.lang.Class<X> filter_type,
                                                                                                        java.lang.Class<T> target,
                                                                                                        java.lang.String key)

get a NumberFieldExpression for a field.

Parameters:

filter_type - type of the hosting object

target - desired numeric type for the field.

key - field name

Returns:

NumberFieldExpression

getBooleanExpression

public <X extends DataObject> BooleanFieldExpression<X> getBooleanExpression(java.lang.Class<X> filter_type,
                                                                             java.lang.String key)

get a BooleanFieldExpression for a field

Parameters:

filter_type - type of hosting object

key - field name

Returns:

BooleanFieldExpression

getStringExpression

public <X extends DataObject> StringFieldExpression<X> getStringExpression(java.lang.Class<X> filter_type,
                                                                           java.lang.String key)

get a StringFieldExpression for a field

Parameters:

filter_type - type of hosting object

key - field name

Returns:

StringFieldExpression

getDateExpression

public <X extends DataObject> FieldValue<java.util.Date,X> getDateExpression(java.lang.Class<X> target,
                                                                             java.lang.String key)

get a Date valued FieldValue for a field. The underlying database field may be a time-stamp or a numeric field.

Parameters:

target - type of hosting object

key - field name

Returns:

FieldValue

getReferenceExpression

public <T extends DataObject> IndexedFieldValue getReferenceExpression(java.lang.Class<T> self,
                                                                       java.lang.String key)

Get a IndexedFieldValue for a reference field

Parameters:

self - type of owning object

key -

Returns:

IndexedFieldValue

getTypeProducerExpression

public <T extends DataObject,O,D> TypeProducerFieldValue<T,O,D> getTypeProducerExpression(TypeProducer<O,D> prod)

getReferenceExpression

public <T extends DataObject,I extends DataObject> IndexedFieldValue<T,I> getReferenceExpression(java.lang.Class<T> self,
                                                                                                 java.lang.String key,
                                                                                                 IndexedProducer<I> prod)

Get a IndexedFieldValue for a field The field does not have to be tagged as a reference field

Parameters:

self -

key -

prod -

Returns:

IndexedFieldValue

insert

protected int insert(Repository.Record r)
              throws DataFault

Default insert operation that uses Generated Keys to obtain the unique id. Not all DBs support this but it is a good default. If the id value is greater than zero this is taken as a required id to be inserted.

Parameters:

r -

Returns:

Throws:

DataFault

setAllowBogusPut

public boolean setAllowBogusPut(boolean f)

control if it is an error to set a property with no corresponding database field.

Parameters:

f - boolean

Returns:

previous value

setAllowNull

public boolean setAllowNull(boolean f)

control if it is an error to set a property with a null value

Parameters:

f - boolean

Returns:

previous value

setFromResultSet

public void setFromResultSet(Repository.Record r,
                             java.sql.ResultSet rs,
                             boolean qualify)
                      throws DataFault,
                             DataNotFoundException

populate an object from a ResultSet It seems to work if we always qualify the field names but its slower

Parameters:

r -

rs - ResultSet

qualify - boolean qualify the field names with the table name as ResultSet is from a join

Throws:

DataFault

DataNotFoundException

ConsistencyError

dbFieldtoTag

public java.lang.String dbFieldtoTag(java.lang.String name)

Map the actual name of the DB field to the tag used in the code. Normally this is the identity but this method allows field renaming.

tagToTable

public static java.lang.String tagToTable(AppContext ctx,
                                          java.lang.String tag)

Map a tag name to the actual database table.

Parameters:

ctx -

tag -

Returns:

table name

setResolution

public void setResolution(long resolution)

Parameters:

resolution - the resolution to set

useID

public boolean useID()

Does this repository support id fields. Without this the table must be read only

Returns:

boolean

usesCache

public boolean usesCache()

usesAlias

public boolean usesAlias()

Returns:

makeTargetObject

public static <T> T makeTargetObject(java.lang.Class<T> target,
                                     java.sql.ResultSet rs,
                                     int pos)
                              throws java.sql.SQLException

Static method to result a field from a result set with a specified target class

Type Parameters:

T -

Parameters:

target -

rs -

pos -

Returns:

T

Throws:

java.sql.SQLException

getForeignKeyDescriptor

public static java.lang.String getForeignKeyDescriptor(AppContext c,
                                                       java.lang.String tag,
                                                       boolean quote)

Get a foreign key descriptor by tag.

Parameters:

c - AppContext

tag - String

quote -

Returns:

descriptor or null

flushCaches

public static void flushCaches(AppContext c)

reset

public static void reset(AppContext c,
                         java.lang.String tag)

Clear the cached repository

Parameters:

c -

tag -

hashCode

public int hashCode()

Overrides:

hashCode in class java.lang.Object

equals

public boolean equals(java.lang.Object obj)

Overrides:

equals in class java.lang.Object

toString

public java.lang.String toString()

Overrides:

toString in class java.lang.Object

cleanup

public void cleanup()

Description copied from interface: AppContextCleanup

AppContext is being closed. Only use this for cleanup that can't be handled by normal garbage collection or for state which is never returned by reference.

Specified by:

cleanup in interface AppContextCleanup

typeName

public static java.lang.String typeName(int type)
